Sanitary Tanks

Mixing tank

This series of containers is suitable for ingredient preparation in the food and pharmaceutical industries. The tank body is jacketed for heating and cooling, and the inner surface is electrolytically mirror polished, conforming to GMP standards.

INQUIRE NOW

CONTACT US

Previous: Mixing tank

Next: Crystallization tank

Product Details

Product Introduction

Consult Now

▎Technical Parameters

Model	Volume（L）	Diameter（mm）	Power（KW）	Agitator speed（RPM）
ZH-PYG-0.5	50	400	0.75	0-200
ZH-PYG-5	500	900	1.5	0-200
ZH-PYG-10	1000	1000	2.2	0-200
ZH-PYG-20	2000	1200	3.0	0-200
ZH-PYG-30	3000	1500	5.5	0-200
ZH-PYG-50	5000	1600	7.5	0-200
ZH-PYG-100	10000	2000	11	0-200
Important Notice: The parameters are for reference only. We can design customized solutions according to your specific requirements.

▎Product Description

This series of containers is suitable for ingredient preparation in the food and pharmaceutical industries. The tank body is jacketed for heating and cooling, and the inner surface is electrolytically mirror polished, conforming to GMP standards.

▎Equipment Features

1. This series of containers has heating and insulation functions.

2. Various sizes are available from 50L to 10000L for your selection. Custom designs and manufacturing are also available to meet specific customer needs.

3. The stirring shaft is sealed with a sanitary mechanical seal. The reducer is selected from German Flender or SEW, with a stirring speed of 60-200 rpm. Variable frequency drive control is also available.

4. The interface uses a universal ISO standard quick-release chuck.

5. The tank body is equipped with a level gauge, air breather, sterilization steam port, thermometer, C1P tank washer, sight glass, multiple inlet/outlet ports, and a manhole.

6. Internal Material: SUS316L/304

Internal Surface Finish: 0.45um

External Material: SUS304

7. Working Pressure: Atmospheric Pressure

Working Temperature: 0-150℃

Sterilization Pressure: 0.21MPa

Sterilization Temperature: 121℃

▎Technical Parameters

Model	Volume（L）	Diameter（mm）	Power（KW）	Agitator speed（RPM）
ZH-PYG-0.5	50	400	0.75	0-200
ZH-PYG-5	500	900	1.5	0-200
ZH-PYG-10	1000	1000	2.2	0-200
ZH-PYG-20	2000	1200	3.0	0-200
ZH-PYG-30	3000	1500	5.5	0-200
ZH-PYG-50	5000	1600	7.5	0-200
ZH-PYG-100	10000	2000	11	0-200
Important Notice: The parameters are for reference only. We can design customized solutions according to your specific requirements.

▎Product Description

This series of containers is suitable for ingredient preparation in the food and pharmaceutical industries. The tank body is jacketed for heating and cooling, and the inner surface is electrolytically mirror polished, conforming to GMP standards.

▎Equipment Features

1. This series of containers has heating and insulation functions.

2. Various sizes are available from 50L to 10000L for your selection. Custom designs and manufacturing are also available to meet specific customer needs.

3. The stirring shaft is sealed with a sanitary mechanical seal. The reducer is selected from German Flender or SEW, with a stirring speed of 60-200 rpm. Variable frequency drive control is also available.

4. The interface uses a universal ISO standard quick-release chuck.

5. The tank body is equipped with a level gauge, air breather, sterilization steam port, thermometer, C1P tank washer, sight glass, multiple inlet/outlet ports, and a manhole.

6. Internal Material: SUS316L/304

Internal Surface Finish: 0.45um

External Material: SUS304

7. Working Pressure: Atmospheric Pressure

Working Temperature: 0-150℃

Sterilization Pressure: 0.21MPa

Sterilization Temperature: 121℃
